3.6.3.1.1.3 PCI Express Root Port 7(82574 Lan)
Item Option Description
PCI Express Root Port 7
Disabled
Enabled[Default]
Control the PCI Express Root
Port.
ASPM Support
Disabled
L0s
L1
L0sL1
Auto[Default]
Set the ASPM Level: Force
L0s-Force all links to L0s State:
AUTO-BIOS auto configure:
DISABLE-Disables ASPM.
PCIe Speed
Auto[Default]
Gen1
Gen2
Select PCI Express port speed.
