EPI-QM77
56 EPI-QM77 User ’s Manual
3.6.2.13.2 Serial Port 2 Configuration
Item Option Description
Serial Port
Enabled,
Disabled[Default]
Enable or Disable Serial Port
(COM)
Change Settings
Auto[Default]
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
Select an optimal setting for
super IO device.
Device mode
Standard Serial Port Mode[Default]
IrDA 1.0 (HP SIR) Mode
ASKIR Mode
Change the Serial Port
mode. Select
or mode.
