Avalue EPI-QM77 - Manual (Page 13)

User ’s Manual
EPI-QM77 User ’s Manual 13
Audio Interface Min In, Line in, Line out (Pin Head 6X2)
Ethernet
LAN Chip
1 x Intel 82574L
1 x Intel 82579 Gigabit PHY
Ethernet Interface 1000 Base-Tx Gigabit Ethernet compatible
Mechanical &
Environmental
Power Requirement +12V~19V, reserve power connector for SATA
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 1.0b and 2.0 Compliant
Power Type AT/ATX
Operating Temp. 32 to 140

F (0 to 60

C)
Operating Humidity 0%~90% relative humidity, non-condensing
Size (L x W) 165mm x 115mm
Weight 0.4lbs(0.18kg)
