EPI-QM87R/ EPI-QM87 User ’s Manual 63
Off
Force Scaling
by the Internal Graphics Device.
Active LFP
No LVDS
eDP Port-A[Default]
Select the Active LFP Configuration. No
LVDS:VBIOS does not enable LVDS.
Int-LVDS. Int-LVDS:BIOS enables LVDS
driver by Integrated encoder. SDVO
LVDS:VBIOS enables LVDS driver by
SDVO encoder. eDP Port-A:LFP Driven
by Int-DisplayPort encoder from Port-A.
eDP Port-D:LFP Driven by Int-DisplayPort
encoder from Port-D9through PCH).
CH7511 EDID Panel Option
1024x768 24/1
800x600 18/1
1024x768 18/1[Default]
1366x768 18/1
1024x600 18/1
1280x800 18/1
1920x1200 24/2
640x480 18/1
800x480 18/1
1920x1080 18/2
1280x1024 24/2
1440x900 18/2
1600x1200 24/2
1366x768 24/1
1920x1080 24/2
1680x1050 24/2
Port-EDP to LVDS(Chrotel7511) Panel
EDID Option.
Backlight brightness
0%
25%
50%[Default]
75%
100%
Select LVDS back light PWM duty.
LVDS Back Light PWM
Frequency
200 Hz[Default]
300 Hz
400 Hz
500 Hz
700 Hz
1 kHz
2 kHz
3 kHz
5 kHz
10 kHz
20 kHz
Select LVDS back light PWM Frequency.
