User’s Manual
EPI-QM87R/ EPI-QM87 User ’s Manual 57
3.6.3.1 PCH-IO Configuration
Item Option Description
PCI Express Configuration PCI Express Configuration settings.
USB Configuration USB Configuration settings.
PCH Azalia Configuration PCH Azalia Configuration settings.
PCH LAN Controller
Disabled
Enabled[Default]
Enable or disable onboard NIC.
SLP_S4 Assertion Width
Disabled
1-2 Seconds
2-3 Seconds
3-4 Seconds
4-5 Seconds[Default]
Select a minimum assertion width
of the SLP_S4# signal.
