EPI-QM87R/ EPI-QM87
42 EPI-QM87R/ EPI-QM87 User ’s Manual
Item Options Description
APCI Sleep State
Suspend Disabled
S3 only(Suspend to
RAM)[Default]
Select ACPI sleep state the system
will enter when the SUSPEND button
is pressed.
S3 Video Repost
Disabled[Default]
Enabled
Enable or Disable S3 Video Repost.
ErP Function
Disabled[Default]
Enabled
Enable or Disable ErP.
Wakeup by Ring
Disabled[Default]
Enabled
Wakeup by Ring from S1~S5.
Watch Dog
Disabled[Default]
30 sec
40 sec
50 sec
1 min
2 min
10 min
30 min
Select WatchDog.
PWRON After PWR-Fail
Off[Default]
On
Former-Sts
Select PWRON After PWR-Fail.
3.6.2.2 S5 RTC Wake Settings
Item Options Description
Wake system with Fixed Time
Disabled[Default],
Enabled
Enable or disable System wake on alarm
event. When enabled, System will wake on the
hr::min::sec specified.
