1.5 System Specifications
System
CPU
Intel® 4th Generation Core™ BGA processors
BIOS
AMI uEFI BIOS,
128 Mbit SPI Flash ROM
System Chipset
Intel QM87 PCH
I/O Chip
EC(IT8518E)
System Memory
1 x 204-pin 1.35V DDR3L 1600/1333MHzSO-DIMM up to 8GB
SSD
1 x mSATA (from Mini PCIe slot)
Watchdog Timer
H/W Reset, 1sec.
– 65535sec./min.
1sec. or 1min. step
H/W Status
Monitor
CPU & system temperature monitoring
Voltages monitoring
Expansion
1 x mini-PCIe (mSATA supported)
I/O
MIO
2 x SATA III, 2 x RS232, 2 x RS232/422/485, LPC
IrDA
FINTEK 81216 (IR Supported )
USB
2 x USB3.0 , 2 x USB 2.0(Wafer),4 x USB 3.0 (Edge connectors)
DIO
4-bit GPI, 4-bit GPO
Display
Chipset
Intel QM87
Resolution
Triple independent display
Dual HDMI+LVDS/ HDMI+LVDS+DVI or Dual HDMI+CRT/ HDMI+LVDS+CRT
LVDS
Dual channel 18/24-bit LVDS
DVI
One DVI port co-lay with VGA
Ethernet
Chipset
1 x Intel I210AT GbE controller
1 x Intel I217LMGbE PHY
Ethernet Interface
10/100/1000 Base-Tx compatible
Audio
Chipset
Realtek ALC892 HD codec support 5.1 channel
Audio Interface
Mic-In, Line-In and Line-Out
Built-in Touch
screen (optional)
Chipset
PenMount 6000
Touch screen
interface
With 9-pin 2.0mm Box Header (can be selected to support 4/5/8 wire touch screen)
