1.5 System Specifications
System
CPU
Intel® Atom™ D510 Dual-Core 1.66GHz CPU or D410/
N450 1.66GHz CPU (Optional)
FSB
533/ 667 MHz
BIOS
AMI 8Mbit Flash BIOS
System Chipset
Intel® ICH8-M
I/O Chip
ITE 8712F-KX
System Memory
One 200-pin SODIMM Supports Up to 2GB DDR2 667
SDRAM
SSD
One CompactFlash Type I/II Socket
Watchdog Timer
Reset: 1sec. ~ 65535min. and 1sec. or 1min./step
Expansion
1 x Mini PCIe Card
I/O
MIO
2 x SATA, 4 x RS-232, 2 x RS-422/ 485,
1 x KB & Mouse (Optional)
USB
6 x USB 2.0
DIO
16-bit General Purpose I/O for DI and DO
Display
Chipset
Intel® Pineview Integrated, GMA3150 @ 400MHz
(PNV D510/ D410)
Intel® Pineview Integrated, GMA500 @ 200MHz
(PNV N450)
Resolution
VGA Mode : Up to 2048 x 1536 @ 60Hz (PNV D510/D410)
VGA Mode : Up to 1400 x 1050 @ 60Hz (PNV N450)
Multiple Display
CRT + LVDS
LCD Interface
Signal 18-bit LVDS for Rev. A1
Dual-channel 24-bit LVDS Via Daughter Board for Rev. B1
Audio
Chipset
Intel® ICH8-M
AC97 Codec
Realtek ALC888 Supports 5.1-CH HD Audio
Audio Interface
Mic-in, Line-in, Line-out
