ECM-KA User’s Manual
ECM-KA User’s Manual 55
Integrated Graphics
Auto[Default]
Disabled
Force
Enable Integrate Graphics Controller.
PSPP Policy
Disabled
Performance
Balanced-High
Balanced-Low[Default]
Power Saving
PCIe Speed Power Policy.
CH7511 EDID Panel Option
1024x768 24/1
800x600 18/1
1024x768 18/1 [Default]
1366x768 18/1
1024x600 18/1
1280x800 18/1
1920x1200 24/2
640x480 18/1
800x480 18/1
1920x1080 18/2
1280x1024 24/2
1440x900 18/2
1600x1200 24/2
1366x768 24/1
1920x1080 24/2
1680x1050 24/2
Port1-EDP to LVDS(Chrotel 7511) Panel
EDID Option.
Backlight brightness
0%
25%
50%
75%
100%[Default]
Select back light duty.
LVDS Back Light PWM
Frequency
200[Default]
300
400
500
700
1K
2K
3K
5K
10K
20K
Select LVDS back light PWM Frequency.
DP0 Output Mode
HDMI[Default]
Disabled
NB PCIE Connect Type (Display Device).
DP1 Output Mode
LVDS
Disabled [Default]
NB PCIE Connect Type (Display Device).
