ECM-KA User’s Manual
50 ECM-KA User’s Manual
3.6.2.8.1 Serial Port 0 Configuration
Item Option Description
Serial Port
Enabled[Default]
Disabled
Enable or Disable Serial Port
(COM).
Change Settings
Auto[Default]
IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12
Select an optimal setting for
Super IO device.
Serial Port 232/422/485
RS232[Default],
RS422,
RS485
Change the Serial Port mode.
Select < RS232> or <
RS485>< RS422> mode.
