ECM-KA User’s Manual
ECM-KA User’s Manual 11
1.5 System Specifications
System
CPU On board AMD Embedded G-Series BGA SoC
BIOS AMI uEFI BIOS, 32Mbit SPI Flash ROM
System Chipset AMD SoC APU integrated chips
I/O Chip ITE8518VG
System Memory 1 x 204-pin s DDR3 SODIMM up to 8GB DDR3 1600 SDRAM
SSD 1 x CompactFlash Type I/II socket (support InnoDisk CF-SATA)
Watchdog Timer H/W Reset, 1sec. – 65535sec.
H/W Status
Monitor
CPU & system temperature monitoring
Voltages monitoring
Expansion 1 x mini-PCIe (mSATA supported)
Display
Chipset AMD SoC APU integrated Graphics
Resolution
CRT Mode: 1920 x 1200 @ 60Hz
HDMI Mode: 1920 x 1080 @ 60Hz
LCD/ Simultaneous Mode: 1920 x 1080 @ 60Hz (Through eDP)
Multiple Display CRT ＋ LVDS, HDMI ＋ LVDS, CRT ＋ HDMI
LCD Interface Dual-channel 18/ 24-bit LVDS
Ethernet
Chipset 2 x RTL8111E Gigabit Ethernet
Ethernet Interface 10/100/1000 Base-Tx compatible
Audio
Chipset Realtek ALC892 support 5.1 –CH Audio
Audio Interface Mic-In, Line-In and Line-Out
I/O
MIO
2 x SATA III
2 x serial (COM2 with 5x2 pitch 2.0mm wafer connector, One COM can be set as
RS-232/422/485(4-wire)selectable by BIOS
1 x K/B & Mouse
USB 2x USB 3.0, 6xUSB 2.0
DIO 4-bit GPI,4-bit GPO
Built-in Touch
screen (optional)
Chipset PenMount 6000
Touch screen
interface
With 9-pin 2.0mm Box Header (can be selected to support 4/5/8 wire touch screen)
