Alwarerc Streak 800 Hexacopter Combo - Manual (Page 18)

6.5 Assembly Steps – ESC and ESC board.
Step 1.
Prepare the Power/ESC Board with
connectors soldered. (Refer to Soldering
Job shown above for more details.)
Step 2.
Prepare 6pcs ESC with connectors soldered.
(Refer to Soldering Job shown above for
more details.)
Step 3.
Insert the Battery Power Cable and Signal
Wire of the ESC into the Carbon Boom Arm.
Step 4.
Pick up the Battery Power Cable and Signal
Wire of the ESC through the specific hole of
Upper Main Frame.
18
