ADLINK NuPRO-E42 - Manual (Page 14)

2 Introduction
1.3 Specifications
NOTE: NOTE:
To purchase the optional DB-Audio2 daughter board, please
contact your ADLINK sales representative.
System
CPU
• Intel® Core™ i7-4770S, 3.1 GHz, 8M Cache, 65W TDP (4C)
• Intel® Core™ i5-4570S, 2.9 GHz, 6M Cache, 65W TDP (4C)
• Intel® Core™ i3-4330S, 3.5 GHz, 3M Cache, 54W TDP (2C)
• Intel® Pentium® G3420, 3.2 GHz, 3M Cache, 54W TDP (2C)
Chipset • Intel® Q87 Platform Controller Hub
Memory
• 2x 240-pin DIMM sockets
• Dual-channel DDR3 1333/1600 MHz (up to 16 GB)
BIOS • AMIBIOS in 64-Mbit SPI Flash
Audio
• Intel® High Definition Audio support via DB-Audio2
daughter board
Watch Dog
Timer • 1-255 second or 1-255 minute programmable and can
generate system reset.
Hardware
Monitor • CPU/System temperature, fan speed and onboard DC
voltage
TPM • Infineon SLB 9635 TT 1.2
Operating
Systems
• Windows XP 32-bit
• WIndows 7/8 32/64-bit
• WIndows Server 2008 R2
• Ubuntu 13.10
I/O Interfaces
