Using the Flat Panel Transfer Board
Included with the nanoX Starter Kit is the Flat Panel Transfer Board (FPTB) which is intended
for prototyping and verification of LVDS and TTL flat panel displays with COM Express
systems. The FPTB is equipped with an LVDS-to-TTL converter to allow users to implement
TTL displays with COM Express systems that support LVDS only. Onboard PWM circuitry
supports backlight control for LVDS and TTL displays.
For detailed instructions on how to connect a TTL flat panel display to the nanoX-BASE using
the FPTB, see Chapter 3 on page 33.
