38 • Power Supply Unit
• Power Fail Signal: available at [FAL#] pin
• Status LED: means valid input voltage; means a
critical fault.
• Thermal Protection (OTP): Installed NTC and thermostat for thermal
sensor at [DEG#] pin
• Power OK: Installed at all outputs
• Leakage Current: 1.18mA at 254Vac/60Hz
Output Characteristics
Output Current (A)
Output
Voltage
Min. Max. Typ. Peak.
5V
0 40.0 25.0 –
3.3V
0 40 20 –
12V
0 5.5 4 –
-12V
0 2 1 –
ƒ Over Load Protection: fully protected against output overload or short circuit,
typical 120% max. load
ƒ Over Current Protection: installed at each rail
o
Output Wattage: Typ. 250W continuous.
o
Output Connector: CompactPCI 47-pin power connector.
o
Line Regulation: Max. ±10mV
o
Load Regulation: 3.3V & 5V: ± 10mV, +12V: ± 30mV & -12V: -380
mV.
o
Noise & Ripple: 60 mV@5V and 3.3V output; 120mV@.± 12V
output.
o
OVP: Built-in at all outputs.
o
Adjustability: Available at VO1, 2 & 3.
o
Output Trim: Electrical trim available at VO1/VO2 [ADJ #].
o
Remote Sensing: Available at VO1, VO2 & VO3.
o
Hot-Swap: Available.
o
N+1 Redundancy: Installed with internal OR-ing diodes at all outputs
for N+1 redundancy operation.
o
Current Sharing: Third-wire current sharing at VO1,2 &3.
o
Power OK Signal: Available for all output.
