Power Supply Unit
Input Characteristics
•
Voltage: 90 – 240 VAC Full Range
•
Frequency : 47 ~ 63 HZ
•
Input Current: 8.0 A ( RMS ) FOR 115 VAC
4.0 A ( RMS ) FOR 230 VAC
•
Inrush Current: 65A MAX. FOR 115 VAC
125A MAX. FOR 230 VAC
Output Characteristics
Output Current(A)
Regulation
Output
Output
Voltage
MIN. MAX.
PEAK LOAD LINE
Ripple&
Noise
Max[P-P]
5V
3
35
–
± 5%
± 1%
50mV
12V
2
30
–
+7 – -5%
± 1%
120mV
-5V
0
0.5
–
± 5%
± 1%
150mV
-12V 0 0.8 –
± 5%
± 1%
150mV
3.3V 1 28 –
± 5%
± 1%
50mV
+5VSB 0.1 2 –
± 5%
± 1%
50mV
Note: The output current of 5V & 3.3V must not exceed 45A.
