Signal Connections

17

29

LTC4

I

Latch input

30

EGND

-

Latch input reference

31

TRG3

O

Trigger output

32

EGND

-

Trigger output reference

33

TRG4

O

Trigger output

34

EA3+

I

A-phase encoder (+)

35

EA3-

I

A-phase encoder (-)

36

EB3+

I

B-phase encoder (+)

37

EB3-

I

B-phase encoder (-)

38

EZ3+

I

Z-phase encoder (+)

39

EZ3-

I

Z-phase encoder (-)

40

EA4+

I

A-phase encoder (+)

41

EA4-

I

A-phase encoder (-)

42

EB4+

I

B-phase encoder (+)

43

EB4-

I

B-phase encoder (-)

44

EZ4+

I

Z-phase encoder (+)

45

EZ4-

I

Z-phase encoder (-)

46

TTL-IN3

I

TTL input signal

47

TTL-IN4

I

TTL input signal

48

TTL-OUT3

O

TTL output signal

49

TTL-OUT4

O

TTL output signal

50

DGND

-

TTL signal ground

CN1No.

Name

I/O

Function
