Introduction

7

PXIe-3985

1.3 I/O and Indicators

1.3.1

Front Panel

Figure 1-2: PXIe-3985 Front Panel

Table 1-1: Front Panel Legend

A

PXI Trigger Connector
(SMB jack)

F

4X Type-A USB 2.0
connectors

B

2X DisplayPort Connectors G

2X Gigabit Ethernet

C

GPIB Connector
(Micro D-Sub 25P)

H

2X USB 3.0

D

Reset Button

I

1X COM port (D-sub9
serial)

E

LED indicators

A

C

G

B

D

F

H

E

I
