20 Installation
Table 2-2: CN1B Pin Assignments
DOUT0 B1 B35 GND
DOUT1 B2 B36 GND
DOUT2 B3 B37 GND
DOUT3 B4 B38 GND
DOUT4 B5 B39 GND
DOUT5 B6 B40 GND
DOUT6 B7 B41 GND
DOUT7 B8 B42 GND
DOUT8 B9 B43 GND
DOUT9 B10 B44 GND
DOUT10 B11 B45 GND
DOUT11 B12 B46 GND
DOUT12 B13 B47 GND
DOUT13 B14 B48 GND
DOUT14 B15 B49 GND
DOUT15 B16 B50 GND
DOUT16 B17 B51 GND
DOUT17 B18 B52 GND
DOUT18 B19 B53 GND
DOUT19 B20 B54 GND
DOUT20 B21 B55 GND
DOUT21 B22 B56 GND
DOUT22 B23 B57 GND
DOUT23 B24 B58 GND
DOUT24 B25 B59 GND
DOUT25 B26 B60 GND
DOUT26 B27 B61 GND
DOUT27 B28 B62 GND
DOUT28 B29 B63 GND
DOUT29 B30 B64 GND
DOUT30 B31 B65 GND
DOUT31 B32 B66 GND
O_REQ B33 B67 O_ACK
O_TRG B34 B68 5Vout
