9 - English
MODEL 28-276 OPEN STAND PARTS
1. Legs (4)
2. Stand Top
3. Long Brace (2)
4. Short Brace (2)
5. Upper Pulley Guard
6. Lower Pulley Guard
7. M10x1.5x80mm Hex Head Screw
8. M10x1.5 Hex Nut
9. Dampening Cap
10. M8x1.25x16mm Round Head Flange Screw (4)
11. M8x1.25x16mm Carriage Head Screw (32)
12. M8x1.25 Hex Flange Nut (38)
13. Shaft (for attaching motor plate to top of stand)
14. 9mm C ring (2)
1
2
3
4
5
6
7 8 9
10
11
12
13 14
