Electrical characteristics curves – Delta Electronics H48SN User Manual
Page 7
ELECTRICAL CHARACTERISTICS CURVES
0.0
5.0
10.0
15.0
20.0
25.0
30.0
0
2
4
6
8
10
12
14
16
18
20
LOAD CURRENT (A)
O
U
T
P
UT
VO
LT
AG
E (
V
)
Vin=48V
Figure 14:
Output voltage ripple at nominal input voltage and
rated load current (20 mV/div). Load capacitance:330uF
aluminum, 1µF ceramic capacitor and 10µFlow ESR capacitor.
Bandwidth: 20 MHz. Scope measurement should be made
using a BNC cable (length shorter than 20 inches). Position the
load between 51 mm to 76 mm (2 inches to 3 inches) from the
module.
Figure
15:
Output voltage vs. load current showing typical
current limit curves and converter shutdown points.
H48SN28012_01172008
7
