Electrical characteristics curves – Delta Electronics H48SN User Manual
Page 4
ELECTRICAL CHARACTERISTICS CURVES
For Negative Remote On/Off Logic
Figure 4:
Turn-on transient at full rated load current (resistive
load) (10ms/div). CH3: Vout;5V/div; CH1: ON/OFF input: 2V/div
Figure
5:
Turn-on transient at minimum load current
(10ms/div). CH3: Vout: 5V/div; CH1: ON/OFF input: 2V/div
For Positive Remote On/Off Logic
Figure 6:
Turn-on transient at full rated load current (resistive
load) (10ms/div). Top Trace: Vout; 5V/div; Bottom Trace:
ON/OFF input: 2V/div
Figure
7:
Turn-on transient at zero load current (10ms/div). Top
Trace: Vout: 5V/div; Bottom Trace: ON/OFF input: 2V/div
H48SN28012_01172008
4
