TECHNICAL SPECIFICATIONS

(T

A

=25°C, airflow rate=600 LFM, V

in

=48Vdc, nominal Vout unless otherwise noted.)

H48SN28012_01172008


2

PARAMETER

NOTES and CONDITIONS

H48SN28012 (Standard)

Min. Typ.

Max. Units

ABSOLUTE MAXIMUM RATINGS

Input Voltage

Continuous

80

Vdc

Transient (100ms)

100ms

100

Vdc

Operating Temperature

Please refer to Fig.21 for measuring point

-40

110

°C

Storage Temperature

-55

125

°C

Input/Output Isolation Voltage

2250

Vdc

INPUT CHARACTERISTICS

Operating Input Voltage

36

48

75

Vdc

Input Under-Voltage Lockout

Turn-On Voltage Threshold

33

35

Vdc

Turn-Off Voltage Threshold

31

33

Vdc

Lockout Hysteresis Voltage

1

3

Vdc

Maximum Input Current

100% Load, 36Vin

12.6

A

Minimum -Load Input Current

260

mA

Off Converter Input Current

Per ETSI EN300 132-2

15

mA

Inrush Current(I

2

t)

0.2

1

A

2

s

Input Reflected-Ripple Current

P-P thru 12µH inductor, 5Hz to 20MHz

12

mA

Input Voltage Ripple Rejection

120 Hz

60

dB

OUTPUT CHARACTERISTICS

Output Voltage Set Point

Vin=48V, Io=Io.max, Tc=25°C

27.72

28.00

28.28

Vdc

Output Voltage Regulation

Over Load

Io=Io,min to Io,max

±

20

±

112

mV

Over Line

Vin=36V to 75V

±

20

±

56

mV

Over Temperature

Tc=-40°C to 100°C

±

250

±

300

mV

Total Output Voltage Range

over sample load, line and temperature

27.25

28.00

28.75

V

Output Voltage Ripple and Noise

5Hz to 20MHz bandwidth

Peak-to-Peak

Full Load, 1µF ceramic, 10µF Low ESR cap

60

150

mV

RMS

Full Load, 1µF ceramic, 10µF Low ESR cap

14

40

mV

Operating Output Current Range

0.3

12.5

A

Output DC Current-Limit Inception

Output Voltage 10% Low

120

%

DYNAMIC CHARACTERISTICS

Output Voltage Current Transient

48V, Tested with a aluminum ,10µF Low ESR cap

and 1µF Ceramic load cap, ΔIo/Δt=1A/10µS

Positive Step Change in Output Current

50% Io.max to 75% Io.max

150

mV

Negative Step Change in Output Current

75% Io.max to 50% Io.max

150

mV

Settling Time (within 1% Vout nominal)

300

us

Turn-On Transient

Start-Up Time, From On/Off Control

20

35

ms

Start-Up Time, From Input

20

35

ms

Output Capacitive Load

Full load; 5% overshoot of Vout at startup 330 5000 µF

EFFICIENCY

100% Load

91.0

%

60% Load

91.5

%

ISOLATION CHARACTERISTICS

Input to Output

2250

Vdc

Input to Case

2250

Vdc

Output to Case

500

Vdc

Isolation Resistance

10

MΩ

Isolation Capacitance

1900

pF

FEATURE CHARACTERISTICS

Switching Frequency

330

kHz

ON/OFF Control Negative Remote On/Off logic

Logic Low (Module On)

Von/off at Ion/off=1.0mA

0

0.8

V

Logic High (Module Off)

Von/off at Ion/off=0.0 µA

15

V

ON/OFF Control, Positive Remote On/Off logic

Logic Low (Module Off)

Von/off at Ion/off=1.0mA

0

0.8

V

Logic High (Module On)

Von/off at Ion/off=0.0 µA

15

V

ON/OFF Current

Ion/off at Von/off=0.0V

1

mA

Leakage Current

Logic High, Von/off=15V

50

uA

Output Voltage Trim Range

Across Pins 9 & 5, Pout ≦ max rated power

-40

+10

%

Output Voltage Remote Sense Range

Pout ≦ max rated power

0.5

V

Output Over-Voltage Protection

Over full temp range; % of nominal Vout

115

140

%

GENERAL SPECIFICATIONS

MTBF

Io=80% of Io, max; Ta=25°C

1.35

M hours

Weight

62

grams

Over-Temperature Shutdown

Please refer to Fig.21 for measuring point

115

°C
