background image

Switch Mode Power Supply DRP024V060W1BA


2/13

Rev: 00,

1/10/2011


Technical Data

60W1Ph

Input Data (1)

Nominal input voltage and frequency

100-240VAC / 50-60Hz

Voltage range

85-264VAC (120

– 375 VDC)

Frequency Range

47-63Hz

Nominal current

1.5A max @115VAC, 1.0A max @230VAC

Inrush current limitation. I2t (+25°C) typ.

< 35A @ 230VAC

Mains buffering at nominal load (typ.)

> 20ms @ 115VAC, > 125ms @ 230VAC

Turn-on time

< 3.0sec.

Internal fuse

T 3.15 AH / 250V

Recommended backup fuse: Power circuit-breaker characteristic

6A, 10A or 16A : B

Leakage current

< 1mA

Energy Star Level

V


Output Data (2)

Nominal output voltage U

N

/ tolerance

24VDC±2%

Setting range of the output voltage

24-28VDC

Nominal current

2.5A

De-rating above +50°C

> 50°C (2.5% / °C)

Startup with capacitive loads

Max 8,000µF at 25°C

Max. power dissipation idling / nominal load approx.

7.4W

Efficiency

> 89% typical.

Residual ripple / peak switching (20 MHz) (at nominal values)

< 50mV / < 150mVpp.

Can be connected in parallel for redundancy and increased capacity

YES with ORing Diode or Redundancy module

Surge voltage protection against internal surge voltages

YES



Certification/Standards

Electrical equipment of machines

IEC60204-1 (overvoltage category III)

Safety transformers for switched-mode power supply units

Electrical safety (of information technology equipment)

TUV BAUART to EN60950-1, UL/C-UL recognized to
UL60950-1, CSA C22.2 No. 60950-1,
CB scheme to IEC60950-1

Industrial Control Equipment

UL / C-UL Listed UL508 and CSA C22.2 No. 107.1-01, CSA to
CSA C22.2 No.107.1-01 (file no. 181564)

Electronic equipment for use in electrical power Installations

EN50178 / IEC62103

Safety entry low voltage

PELV (EN60204), SELV (EN60950)

Safe isolation

DIN.VDE 0100-410

Protection against electric shock

DIN 57100-410

Protection against shock currents, basic requirements for protective
separation in electrical equipment

VDE 0106-101

Limitation of mains harmonic currents

DIN57100-410
