www.desatech.com 113135-01A 29
PARTS LIST
FIREPLACE MODELS
VSGF28NTE AND VSGF28PTE
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 25 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 ** Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-18 Louver Extruded 2
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 ** Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 101346-01 Outer Base 1
14 ** Firebox Wrapper 1
15 101614-02 Limit Switch (thermal disk) Assy. 1
16 M11084-26 Hex Screw, #10 57
17 098304-02 Phillips Pan Head Screw, #6-20x.38 4
18 101727-03 Screen Assembly 1
19 101398-03 Wire Harness 1
20 103650-01 Control Knob 1
21 103581-02 Blower Assembly 1
22 099123-01 Wire Clip 4
23 105649-01 Blower Speed Control 1
24 M11084-38 Hex Screw, 8-18 x .38" 4
25 101629-01 Plastic Bushing 2
26 098544-01 Clamp 1
PARTS AVAILABLE — NOT SHOWN
099038-01 Strain Relief Bushing 1
100639-01 Caution Decal 1
104313-01 Hinge, Pin 1
104313-02 Hinge, Pin 1
M10908-2 Screw, Slotted Hex Head Tapping 4
** Not a field replaceable part.
