www.desatech.com 113135-01A 27
KEY PART NUMBER
NO. VSGF28NTE VSGF28PTE DESCRIPTION QTY.
1 110881-01 110881-01 Front Log (#1) 1
2 110881-02 110881-02 Middle Log (#2) 1
3 110881-03 110881-03 Rear Log (#3) 1
4 M11084-38 M11084-38 Screw 2
5 098304-01 098304-01 Screw, #10 Phillips, Black 8
6 104285-01 104286-01 ODS Pilot 1
7 098249-01 098249-01 Nut 4
8 101006-02 101006-02 Pilot Bracket 1
9 101330-05 101330-05 Front Burner Assembly 1
10 109824-02 109824-02 Rear Burner Assembly 1
11 ** ** Base Assembly 1
12 098271-06 098271-06 Ignitor Cable 1
13 ** ** Firebox Bottom 1
14 098867-09 098867-10 Gas Regulator 1
15 101004-04 101004-15 Front Burner Injector 1
16 102845-01 102845-01 Inlet Tube 1
17 101382-01 101382-01 Thermovalve Bracket 1
18 099387-03 099387-03 Pilot Tube 1
19 102846-01 102846-01 Burner Tube 1
20 097809-02 097809-02 Adapter 1
21 099211-01 099211-01 Screw 2
22 098544-01 098544-01 Thermostat Clamp 1
23 101329-20 101329-26 Thermostat Gas Valve Assembly 1
24 101381-01 101381-01 Cover and Piezo 1
25 101004-14 101004-10 Rear Burner Injector 1
26 M11084-26 M11084-26 Hex Screw, #10 2
27 101628-03 101628-03 Flex Hose 1
28 901063-01 901063-01 3/8" Flare x 1/2" NPT 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101054-01 101054-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
** Not a field replaceable part.
PARTS LIST
LOG BASE ASSEMBLY
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 25 of this manual.
