REFERENCE

59

General

Power requirements

200–240V~, 50/60 Hz

Power consumption Operation : Maximum 26W

Standby : 5W

Dimensions(approx.) 430 *92 *312 (w*h*d)
Mass (approx.)

4.96 Kg

Operating temperature 5°C to 35°C
Operating humidity

5% to 90%

Signal system

PAL Colour

Recording

Recording formats

DVD Video Recording, DVD-
VIDEO

Recordable discs

DVD±R, DVD±RW

Recordable time

[DVD] (Approx.) 1 hour (HQ
mode), 2 hours (SP mode), 4
hours (EP mode), 8 hours
(SEP mode)
[VCR] SP: 3 Hours (E-180),
LP : 6 Hours (E-180)

Video recording format

Sampling frequency 27MHz
Compression format MPEG 2

Audio recording format

Sampling frequency 48kHz
Compression format MPEG1 Layer2

VCR Specifications

Head system

4 Head Video, 2 Head Hi-Fi
helical scan azimuth system

Timer

24-hour display type

Tape speed

SP: 23.39 mm/sec
LP: 11.70 mm/sec

Tape width

12.7 mm

Rewind time

less than 150 sec (E-180)

Channel coverage

VHF:2-12,13-20,74-80 /

UHF:21-

69 / CATV:1-41

Frequency range

20Hz to 20kHz

Signal-to-noise ratio 43 dB
Dynamic range

75 dB

Channel separation

45 dB

DVD Specifications

Laser system

Semiconductor laser,
wavelength 650 nm

Frequency response DVD (PCM 48 kHz): 8 Hz to 22

kHz, CD: 8 Hz to 20 kHz

Video S/N

More than 60 dB

Audio S/N

More than 90 dB

Harmonic distortion

Less than 0.06%

Dynamic range

More than 90 dB

Resolution

Over 500 lines (HQ Recording)

Inputs

Antenna In

Antenna or CATV input, 75 Ω

Video In

1.0 Vp-p 75 Ω, sync negative,
RCA jack x 2

Audio In

-8.8 dBm more than 47 k, RCA
jack (L, R) x 2

DV IN

4pin (i.LINK/IEEE 1394

standard)

USB In/Out

Series ‘A’ Connector (USB 2.0
Full Speed)

Outputs

Video Out

Composite output (1.0 Vp-p,
unbalanced) RGB output (75 in
load, R:0.7Vp-p, G:0.7Vp-p,
B:0.7Vp-p)

Component Video Out (Progressive Scan)

(Y) 1.0 V (p-p), 75 Ω, negative

sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω,
RCA jack x 2

Audio Out

Digital audio : 0.5 V (p-p), 75
Ω, RCA jack x 1
Analog audio : 1.1 Vrms (1kHz,
-6 dB), 600 Ω, RCA jack (L, R)
x 2

HDMI video/audio output

19 pin (HDMI standard, Type
A)

Accessories

RF cable .................................................................. 1
Remote control ........................................................ 1
Batteries .................................................................. 2

Design and specifications are subject to change

without notice.

Technical Specifications

Technical Specifications

Manufactured under license from Dolby
Laboratories. ‘Dolby‘ and the double-D symbol are
trademarks of Dolby Laboratories.
DTS and DTS Digital Out are registered
trademarks of Digital Theater Systems, Inc.
