Specifications
CONTROLS
stereo tie switch
defeat switch
gain:
ratio:
attack time:
release time:
output:
Detector Patch Point:
Maximum Input/Output Level:
Input Impedance:
Output Impedance:
Frequency Response:
Distortion:
Hum and Noise:
Power Requirements:
Size:
Shipping Weight:
Block Diagram
Many interesting and productive effects can be
achieved by combining the CL-50E or the CL-52E with
Ashly’s SG-33E or SG-35E Noise Gates.
(CL-52E ONLY)
±30dB
2:1-<»
200
m
S. - 20mS.
lOOmS - 2Sec.
-40dBV - +20dBV
allows the connection of an EQ for
frequency selective limiting
+20dBm
lOkQ balanced bridging
50ii term, w/ 600£2 or more
±.2dB 20Hz - 20kHz
<•015% THD, OdBV 20 Hz • 20kHz, no limiting
<•15% +i8dBV worst case
-95dBV unity gain
120 VAC, 50-60HZ, 5W
19" L
X
1 3/4"H
X
6"D
8lbs
Architect’s Specification
The unit shall be a single (CL'50E) or dual (CLr
52E) channel compressor/limlter with indepen
dent attack, release and ratio adjustments. It
shall have detector patch points which allow con
nection of an external equalizer in the detector
loop to produce frequency selective limiting. It
shall have front panel mounted switches for
engaging/ defeating the compressor/llmiter func
tions. Performance specifications of a typical
production unit shall meet or exceed the follow
ing: Gain control shall be +30dB. The ratio shall
be adjustable from 2:1 to «. The attack time shall
be adjustable from 200^iS to 20mS. The release
time shall be adjustable from lOOmS to 2 sec
onds. The output shall be adjustable from -40dBV
to ■i-20dBV. The maximum in-out level shall be
+20dBm, The input impedance shall be lOkii bal
anced bridging. The output impedance shall he
50£2 terminated with 60011 or more. The frequen
cy response shall be 20Hz to 20kHz l.ZdB.
Distortion shall be <.015% THD @ OdBV from
20Hz to 20kHz with no limiting, <.15% @4^1SdBV
worst case. Hum and noise shall not exceed -
90dBV @ unity gain. The unit shall operate at
115VAC ±5%. 50-60HZ. The unit shall be
designed for mounting in a standard ElA 19'' rack
(19'"L X 1.75"H X 6"D) and shall have a shipping
weight of 8 lbs. The imit shall be either a model
CL-50E (single channel) or a CL-52E (dual chan
nel) Compressor/Limiter manufactured by Ashly
Audio Inc. No other unit shall be acceptable
unless submitted data from an independent
research lab verifies that the above slze/perfor-
mance specs are met.
