Dayton Operating Instructions and Parts Manual
17
®
Models 3E358B and 3E359B
Repair Parts List
Reference
Number
Description
Part Number
Qty.
1
Wiring cover
097492-03
1
2
5/16-24 x 5/16" Screw
*HF5-5C
4
3
5/16" External lockwasher *WLE-5
4
4
#10-16 x 3/8" Screw
*M11084-26
3
5
Motor (Model 3E358B)
099562-01
1
Motor (Model 3E359B)
099562-02
1
6
Flange clamp
M50116
1
(holds pump to motor)
7
Motor support
099518-05
1
(Model 3E358B)
Motor support
099519-03
1
(Model 3E359B)
8
Compression elbow
M50297
1
9
Fuel pump kit
098560-02
1
10
Filter element
110381-01
1
(inside fuel pump,
includes gaskets)
11
Straight fitting
M50113-02
2
Motor and Pump Assembly for Heaters with Fuel Filter Internal to Pump - Figure 23
12
#8-32 x 3/8" Screw
M10908-14
1
13
Strain relief bushing
101504-01
1
14
5/16" Lockwasher
*WLM-5
4
15
5/16-24" Hex nut
NPF-5C
4
16
Flamezzrol
HA3003
1
17
Snap bushing
101547-01
3
18
#6-32 x 3/8" Screw
M10908-2
2
19
Power relay
097491-01
1
20
Terminal Board
099125-05
1
21
Terminal Board
099125-04
1
22
Rivet
099157-01
2
Reference
Number
Description
Part Number
Qty.
(*) Standard hardware item, available locally.
3E358B and 3E359B
Reference
Number
Description
Part Number
Qty.
1
Wiring cover
097492-03
1
2
5/16-24 x 5/16" Screw
*HF5-5C
4
3
5/16" External lockwasher *WLE-5
4
4
#10-16 x 3/8" Screw
*M11084-26
3
5
Motor (Model 3E358B)
099562-01
1
Motor (Model 3E359B)
099562-02
1
6
Flange clamp
M50116
1
(holds pump to motor)
7
Motor support
099518-05
1
(Model 3E358B)
Motor support
099519-03
1
(Model 3E359B)
8
Street elbow
57413
2
9
Pipe nipple
M17499-2
1
10
Fuel filter assembly
098102-01
1
Filter element
098103-01
1
(inside fuel filter assembly,
includes rubber gaskets)
Motor and Pump Assembly for Heaters with Fuel Filter/Canister External to Pump - Figure 24
11
90˚ Male elbow
M50114-02
1
12
Compression elbow
M50297
1
13
Straight fitting
M50113-02
1
14
Fuel pump kit
098560-01
1
15
5/16" Lockwasher
*WLM-5
4
16
5/16-24" Hex nut
NPF-5C
4
17
Flameout control
HA3003
1
18
Power relay
097491-01
1
19
Snap bushing
101547-01
3
20
#6-32 x 3/8" Screw
M10908-2
2
21
Strain relief bushing
101504-01
1
22
#8-32 x 3/8" Screw
M10908-14
1
23
Terminal Board
099125-05
1
24
Terminal Board
099125-04
1
25
Rivet
099157-01
2
Reference
Number
Description
Part Number
Qty.
(*) Standard hardware item, available locally.
