Dayton 2E510D - Manual

Operating Instructions & Parts Manual
Dayton Portable
Oil-Fired Heaters
®
Form 5S1792
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Unpacking
1. Remove all packing items supplied
with heater for shipment.
2. Remove all items from carton.
3. Check heater for any shipping
damage. If heater is damaged,
promptly inform dealer where you
bought heater.
2E510D, 2E511D, 3E218D, and 3E219C
Version B - For Reduction G016.J
®
Figure 1 – Models 2E510D and 2E511D Figure 2 – Models 3E218D and 3E219C
ARL LOGO G 004
®
Description
The Dayton models 2E510D, 2E511D, 3E218D, and 3E219C heaters are 30,000 to
150,000 Btu/Hr heaters. These heaters use Kerosene #1 fuel oil for combustion
and electricity to run the motor. They are primarily intended for indoor and
outdoor temporary heating of buildings under construction, alteration, or repair.
They may be used in agricultural, industrial, and commercial environments.
Output Fuel Tank Capacity Fuel Consumption
Model Rating Btu Fuel (U.S. Gallons) (U.S. Gallons/Hr.) Motor RPM
2E510D 35,000 Kerosene or No. 1 fuel oil 3.0 0.3 1725
2E511D 55,000 Kerosene or No. 1 fuel oil 5.0 0.4 1725
3E218D 110,000 Kerosene or No. 1 fuel oil 9.0 0.8 3450
3E219C 150,000 Kerosene or No. 1 fuel oil 13.5 1.1 3450
Hot Air Air Pump Shipping Weight Heater Weight Spark Plug Gap
Model Output (CFM) Pressure (PSI) (Pounds) (Pounds - without fuel) (Inches)
2E510D 165 3.0 38 35 .055
2E511D 175 3.4 39 36 .075
3E218D 490 4.5 65 55 .075
3E219C 500 5.0 65 55 .075
