General Specifications Powerflex-670
Crosstalk:
< -75dB (20Hz - 1KHz)
*Power Output
(Maximum Average Power, 0.1% THD, 1KHz)
Signal Present Signal Sensitivity:
14mV RMS (-34.9dBu)
Rated Per Channel, Two Channels Driven
Power Requirement:
110-125VAC, 220 - 250VAC, 50/60Hz
70V:
300 Watts RMS
140V (Mono Bridged-1, Channel):
600 Watts RMS
Typical Idle Current
120V:
0.9A
Rated Per Channel, Six Channels Driven
240V:
0.5A
70V:
200 Watts RMS
140V (Mono Bridged, 3 channels):
400 Watts RMS
Current with Typical Audio Program Material (6 Channels Driven)
120V:
10A
Input Impedance:
10K ohm balanced, 37K ohm unbalanced
240V:
5A
High Pass Filter:
80Hz, 12dB/octave, internally selectable
Connections
Input:
Eurobloc
**THD (20Hz - 20KHz, 200W , 6-Channels Driven):
<0.5%
Output:
Screw Terminal
**IMD
Cooling:
Forced Air, Thermal Sensitive 2-Speed Fan, Front Inlet/Rear
(SMPTE 60Hz/7KHz 4:1):
<0.2%
Outlet
**Hum and Noise:
< -100dB from full output (A-weighted)
Dimensions:
19"L x 5.25"H x 16.5"D
Full Power Input Sensitivity:
1.4V RMS (5.1dBu)
Construction:
All-Steel Chassis, Extruded Aluminum Front Panel
Frequency Response:
±0.5dB (20Hz-20kHz, full power)
W eight:
47 lbs. net, 54 lbs. shipping
Voltage Gain:
50X (34.0dB)
Specification conditions are:
120VAC mains at 60Hz, 25° C
* Continuous power limited by power line capacity
**Non-conventional amplifiers require bandwidth limiting for all distortion and noise measurements
Signal peaks in audio programming may trigger protection circuitry at low line voltages
Specifications are subject to change or improvement without notice
Rear Panel Powerflex-670
Applications:
Any 70V and 140Vmultichannel power amplification application, paging systems, sound masking systems, cinema systems, board
room audio applications, multiple zone restaurant, bar, theme park or auditorium systems.
Ashly manufactures a complete and comprehensive line of Graphic and Parametric Equalizers,
Electronic Crossovers, Power Amplifiers, Compressor-Limiters, Mixers, and
Amplifier Input Options. Please call, write or visit our web site for information on any of these Ashly Products.
