Specifications
CONTROLS
Input Level:
Response Control:
Output Level:
oo -
+6dB
1.5dB-12dB
oo - +20dB
Input Impedance:
Maximum Input Level:
Maximum Output Level:
Frequency Response:
Distortion:
Slew Rate:
Hum and Noise:
Power Requirements:
Size:
Shipping Weight:
Block Diagram XR-3000
Ashly also manufactures a
complete and comprehen
sive line of 12dB per Octave
Electronic Crossovers as
well as Power Amplifiers,
Compressor/Limiters, Noise
Gates, Graphic and
Parametric Equalizers, and
Preamps. Please call or write
for information on any of
these Ashly Products.
Typical Hookup Of XR-2000 in 4-Channel, Two-
Way Operation (Multiple-Mix Stage Monitors)
FROM
FROM OUTPUT
FILTERS STAGES
PEAK INDICATOR
POWER
MONITOR
10ki2 balanced bridging
•l■26dBm
•F20dBm
±.5dB 20Hz-20kHz
<.05% THD
6V/pS
-90dBv
120VAC, 50-60HZ, 5W
XR-1000, XR-3000: 19"L x 1.75"H x 6"D
XR-2000, XR-4000: 19"L x 3.5"H x 6"D
XR-1000, XR-3000: 8 lbs.
XR-2000, XR-4000: 10 lbs.
FILTERS
Typical Hookup Of XR-1000 in
Mono, Three-Way Operation
OUTPUT STAGES
Typical Hookup Of XR-1000 in
Stereo, Two-Way Operation
