Bolens 112-413R352 - Manual (Page 15)

Models 413R and 428R
PARTS LIST FOR MODELS 413R AND 420R ROTARY MOWERS
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 747-0824 N Control Handle Ass’y. 50 736-0356 Bell-Wash. .39" I.D.
3 710-0605 N Oval C-Sunk Mach.-Scr. 51 712-0798 Hex Nut 3/8-16 Thd.*
4 736-0501 N Spr. Wash. .66" I.D. 52 710-0654A Hex L-Wash. Hd. Scr.
5 712-0291 Hex L-Nut 1/4-20 Thd. 3/8-16x1" Lg.
6 746-0875 N Throttle Body 53 16998A 638/N 21" Deck Ass’y.
7 712-0324 Hex L-Nut 1/4-20 Thd. 54 17014 Chute Baffle
8 749-0438B Upper Handle 55 17003 Retaining Strip 14.25" Lg.
9 746-0876 N Throttle Lever 56 731-0669 Rear Flap 17.30" Lg.
10 736-0270 Bell-Wash. 1/4" I.D. 57 731-0859 Rear Chute Deflector
11 710-0252 Hex Bolt 1/4-20 x .85"* 58 731-0856 Hardtop Handleft
12 746-0845 N Throttle Control Wire—45" 59 731-0857A Hardtop Bag Covertt
(413R) 60 749-0736A Rear Catcher Frameft
746-0843 N Throttle Control Wire—55" 61 764-0411 Front Catcher Frameft
(42gR) 62 764-0252 Grass Bagtt
13 710-1205 Rope Guide 65 736-0463 FI-Wash. .281" I.D.ff
14 736-0119 L-Wash. 5/16" I.D.* 67 764-0246 Grass Bagt
15 712-0267 Hex Nut 5/16-18 Thd.* 68 731-0801 Bag Handlef
16 746-0555 Control Cable—55" (413R) 69 749-0764A Rear Catcher Framef
746-0554 Control Cable—40.5" (42^R) 70 764-0412 Front Catcher Framef
17 726-0240 Cable Tie 71 710-1025 Hex AB-Tap Scr. #12x1.25"f
18 710-0671 Curved Carriage Bolt 5/16-18 72 736-0452 Bell-Wash. .39" I.D.
xl.38" Lg. 73 742-0306A 21" Blade
19 749-0504C Lower Handle 74 753-0484 Blade Adapter Kit
20 811-00185 Throttle Box Comp. (Incl. Ref. 3, 75 710-1044 Hex Bolt 3/8-24 x 1.5" Lg.
4, 5, 6, 9) 76 15261A Height Adj. Plate
751-0568 N Cable Clamp (426R) 77 15262B Pivot Bar
K21 710-1237 N Hex Self-Tap Scr. #10-32 x .62" 78 14832 Spring Lever Ass’y. w/Knob
Lg. (420R) 79 738-0507B ShId. Bolt .50" Dia. x .357"
22 735-0639 Spark Plug Boot (Optional) 80 736-0105 Bell-Wash. .38" I.D. x .88" O.D.
23 17007 Baffle 82 14578 Height Adj. Ass’y. Comp.—R.H.
27 — Engine 14579 Height Adj. Ass’y.
31 710-1055 Hex Bolt 3/8-24 x 1" Comp.—L.H. (Not Shown)
32 736-0169 L-Wash. 3/8" I.D. 83 734-1608 Wheel Ass’y. Comp.
33 712-0241 Hex Nut 3/8-24 Thd. (Spoked Rim Ass’y.)
34 731-0858 Seal—Extrusion 634-0020 N Wheel Ass’y. Comp. (Smooth
35 714-0104 Int. Cotter Pin 5/16" Dia. Rim Ass’y.)! A ft XREft’b
36 726-0106 Cap Speed Nut 84 14764C Index Plate
37 747-0698B Hinge Pin 17.75" Lg. 85 14765 Pivot Bar—R.H.
38 750-0566 Spacer .255" I.D. 14766 Pivot Bar—L.H. (Not Shown)
39 732-0577B N Torsion Spring—L.H. 86 720-0190 Spring Lever Knob
40 711-0805 Shid. Pin 3/8-24 X 1.43" Lg. 87 732-0417A Spring Lever
41 736-0169 L-Wash. 3/8" I.D.* 88 16106 Rear Height Adj. Ass’y.
42 712-0711 Hex Jam Nut 3/8-24 Thd. Comp.—R.H.
43 732-0578B N Torsion Spring—R.H. 16107 Rear Height Adj. Ass’y.
44 12297A Handle Brkt. Ass’y.—L.H. Comp.—L.H. (Not Shown)
45 710-1017 Torx Mach. AB-Tap Scr. 1/4 x 89 738-0102 Axle Bolt
.62" Lg. 92 720-0224 Grass Catcher Locking Knobff
46 731-0970B Deflector Plug 93 736-0498 Internal L-Wash. 1/4" I.D.ff
47 731-0931 Corner Plug 94 736-0286 Wave Washer 3/8" I.D.ff
48 12296A Handle Brkt. Ass’y.—R.H. 95 738-0137 Shid. Bolt .342" Dia. x .268"ff
49 710-0892 Hex L-Wash. AB-Tap Scr. 96 731-0564 Plug
1/4 X .62" Lg.
t Model 413R (Softtop grass bag) only,
ft Model 420R (Hardtop grass bag) only.
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
15
NOTE: The engine is not under warranty by the
mower manufacturer. . .If repairs or service is
needed on the engine, please contact your
nearest authorized engine
service outlet. Check the
“Yellow Pages” of your
telephone
book under
“Engines-Gasollne.”
