Bolens 247.77010 - Manual (Page 17)

Sears Craftsman 4,5 H.P. Yard Vacuum Mode! 247.77010
REF
NO.
PART
NO.
DESCRIPTION REF
NO.
PART
NO.
DESCRIPTION
1 725-1700 Switch Cover 21 710-1054 Hex Screw 5/16-24 x 1.0
2 725-3166 Safety Switch 22 781-0490 Chipper Blade
3 710-0224 Hex Washer Screw #10-16 x .50 23 736-0119 Lock Washer 5/16
4 629-0920 Wire Harness 24 712-0411 Hex Lock Nut 5/16-24
5 710-0604 Hex Washer Screw 5/16-18 x .625 25 681-0152 Impeller Ass’y
6 714-0104 Cotter Pin 26 719-0329 Flail Blade
7 736-0264 Flat Washer .330 ID x .630 OD 27 781-0735 Pin Clip
8 732-0962 Compression Spring 28 711-0833B Clevis Pin
9 781-0778 Mounting Bracket 29 715-0166 Spiral Pin
10 747-1153 Lock Rod 30 736-0247 Flat Washer 3/8 ID x 1.25 OD
11 710-3008 Hex Cap Screw 5/16-18 x .75 31 736-0217 Lock Washer 3/8
12 681-0122 Chipper Chute Ass’y 32 710-0818 Hex Cap Screw 3/8-24 x 2.0
13 726-0454 U-Clip Lock Nut 5/16-18 33 681-0154 Screen Ass’y
15 710-0502A Hex Washer Screw 3/8-16 x 1.25 34 710-3038 Hex Cap Screw 5/16-18 x .875
16 710-0969 Screw #12-16 X 1.0 35 781-0721 Lower Housing
17 710-3195 Hex Cap Screw 5/16-18 x 4.5 36 712-3004A Lock Nut 5/16-18
18 710-3025 Hex Cap Screw 5/16-18 x .625 37 731-1905 Nozzle Cover
20 781-0720 Upper Housing 38 712-0158 Lock Nut 5/16-18
17
