PARTS LIST FOR FRAME VIEW MODEL 139-402A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART 1 COLOR
NO. 1 CODE
DESCRIPTION
NEW
PART
1 731-0220 Steering Wheel Cap 48 12147 Rear Axle Support Brkt.
2 712-0158 Hex Cent. L-Nut 5/16-18 Thd. 49 10470 Bearing—Plate
3 736-0242 Belleville Wash. 50 741-0199 FIng. Brg. w/Flats .751 I.D.
4 731 -0219 Steering Wheel Ass’y- 51 717-0328 Differential Ass’y.—Comp.
5 731 -0262 Cover—Steering Column 52 12148 Axle Brkt.
6
750-0233 Steering Tube Ass’y. 53 736-0134 FI-Wash. .812 I.D. x1.38
7 738-0140 Shld. Scr. .437 Dia. x .180” O.D.
Lg. 54 734-0522 Wheel Ass’y—Comp. Rear
8 12138 Steering Shaft Ass’y. 12.2x3.7
9 712-0222 Push Speed Nut .62 Dia. 55 736-0105 Belleville Wash. .400 I.D. x
10 736-0156 FI-Wash. .635 I.D. x 1.120 .88 O.D.
O.D. 56 710-0627 Hex Scr. 5/16-24 X. 75” Lg.
11 748-0227 Hex Flange Brg. .630 I.D. 57 736-0119 L-Wash. 5/16” Scr.*
12 712-0267 Hex Nut5/16-18Thd.* 58 712-0267 Hex Nut 5/16-18 Thd. *
13 736-0119 L-Wash. 5/16” Scr.* 59 710-0198 Hex Sems Scr. 5/16-18 x
14 712-0107 Hex Cent. L-Nut V4-20 Thd. .75” Lg.*
15 710-0428 Hex Scr. 1/4-28x1.25” Lg.* 60 712-0267 Hex Nut5/16-18Thd.*
16 12125 Main Frame 61 736-0119 L-Wash. 5/16” Scr.*
17 712-0267 HexNut5/16-18Thd.* 62 710-0395 Hex Scr. 5/16-18x2.25” Lg.*
18 736-0119 L-Wash. 5/16” Scr.* 63 09780 Belt Guard Ass'y.—Trans.
19 712-0267 Hex Nut 5/16-18 Thd.* 64 761 -0130 Disc Brake Ass’y.
20 736-0119 L-Wash. 5/16” Scr.* 65 12145 Brake Brkt. Ass’y.
21 710-0198 Hex Sems Scr. 5/16-18 x 66 732-0118 Ext. Spring
.75” Lg.* 67 710-0117 Hex Scr. 5/16-24x1.00” Lg.
22 09709 Axle Ass’y. —Front—L.H. H.T.
23 710-0198 Hex Sems Scr. 5/16-18 x 68 710-0198 Hex Sems Scr. 5/16-18 x .75”
.75” Lg.* Lg.*
24 747-0147 Tie Rod 3/8” Dia. L.H. 69 761 -0133 Spacer for Disc Brake
25 09706 Axle Ass’y.—Front—R.H. 70 710-0198 Hex Sems Scr. 5/16-18 x .75”
26 711-0169 Collar Lg.*
27 710-0666 Sq. Hd. Set Scr. 5/16-18 x 71 10247 Transmission Plate
.38 Cup 72 713-0723 #41 Master Link Vz” Pitch
28 748-0146 Flange Brg. w/ Flats .630 Type II
I.D. 73 713-0190 #41 (¿hain Vz” Pitch x71 Links
29 734-0510
Wheel Ass’y.—Front 10.25 x 74 717-0223 Single Spd. Trans.—Comp.
3.25 75 715-0103 Spring Pin Roll 1 /8” x .75”
30 714-0507 Cotter Pin 3/32” Dia. x .75” Lg.
Lg.* 76 12170 Shift Brkt. Ass’y.
31 12151 Front Wheel Brkt. 77 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
32 710-0198 Hex Sems Scr. 5/16-18 x 78 747-0136 Shift Rod
.75” Lg.* 79 12150 Index and Support Brkt.
33 712-0375 Hex Cent. L-Nut 3/8-16 Thd. 80 712-0267 Hex Nut 5/16-18 Thd.*
34 738-0234 Shld. Scr. .500” Dia. x .295” 81 736-0119 L-Wash. 5/16” scr.*
Lg. 82 12169 Shift Lever
35 712-0267 Hex Nut 5/16-18 Thd.* 83 720-0142 Grip—Flat Bar Type
36 736-0119 L-Wash. 5/16” Scr.* 84 712-0134 Hex Top L-Nut 5/16-24 Thd.
37 12155 Pedal Pivot Brkt. w/Va” Hole 85 HH-03-03032 Wash. .349 I.D. X 1.004 O.D.
38 12156 Pedal Pivot Brkt. w/3/8” X .066 Thk.
Hole 86 HH-18-03493 Cam Lever 22°
39 12136 Brake Pedal Ass’y. 87 HH-06-03031 Spring—Compres. .350” Dia.
40 12419 Pedal Lockout Rod 5/16” X 4 Coils
Rod 88 HH-05-03034 Push Pin .309” Dia. x .857”
41 714-0104 Int. Cotter Pin 5/16” Dia.* Lg.
42 726-0109 Push Cap—.312 I.D. 89 HH-12-03292 Casting—Cam
43 747-0128 Brake Rod V4” Dia. x 25.25” 90 HH-03-03303 Back-up Wash. 1.115” Dia. x
Lg.
.08 Thk. (D-Shaped)
44 732-0245 Brake Spring 91 HH-15-02124 Pad—Friction (D-Shaped)
45 710-0198 Hex Sems Scr. 5/16-18 x .75 1.110” Dia. x .472 Thk.
Lg.* 92 HH-15-03149 Pad Friction (D-Shaped)
46 712-0267 Hex Nut 5/16-18 Thd.* 1.110” Dia. X. 245Thk.
47 736-0119 L-Wash. 5/16” Scr.* 93 HH-12-03293 Casting—Carrier
94 747-0146 Tie Rod 3/8” Dia.—R.H.
1____
95 712-0158 Hex Cent. L-Nut 5/16-18 Thd.
(462—Red Flake)
When ordering parts, if color or finish is important use the
appropriate color code shown above (e.g. Red Flake
Finish-12131 (462).)
21
*For faster service obtain standard nuts, bolts and washers
locally. If these Items cannot be obtained locally, order by
part number and size as shown on parts list.
