Bolens 139-402A - Manual (Page 16)

139-402A
PARTS LIST FOR DIFFERENTIAL ASSEMBLY 717-0328
REF,
NO.
PART
NO.
Qty.
Req’d., DESCRIPTION
NEW
PART
1 715-0247 2 Spring Pin Spir. 3/16” Dia. x
1.00” Lg.
2 748-0185 2 Gear—Double “0” Hole
3 738-0300 1 Shaft—Long 19.31 ” Lg.
4 736-0188 2 FI-Wash. .760 I.D. x 1.49 O.D.
5 717-0341 2 Housing Half
6 736-0119 2 L-Wash. 5/16”Scr.*
7 710-0363 2 Hex Scr. 5/16-24x4.00” Lg.*
8 736-0187 2 Fl-Wash. .640 I.D. X 1.24 G.D.
9 748-0158 2 Gear—Round Hole
10 711-0276 1 Drive Pin
11 712-0237 2 Hex Gent. L-Nut 5/16-24 Thd.
12 09054 1 Sprocket—40 Tooth
13 738-0301 1 Shaft—Short 7.07" Lg.
‘For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list,
16
