PARTS LIST FOR ROTARY MOWER MODEL NO. 113-530 A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
80
8376
Lockout Bracket Ass'y.
81
8373
Lockout Lever Ass'y.
82
720-157
Grip
N
83
9354
Handle - Upper
84
8378
Clamp Bracket
85
712-526
Speed Nut - 10-24 Thd. *
87
746-128
Cable Clip
88
734-180
Wheel Assembly - 16" less Tire (Rear)
89
741-113
Ball Bearing (Rear)
90
734
Axle Bolt (Rear)
91
736-105
Belleville Washer
92
710-209
Sems Hex Hd. Cap Scr. 3/8-16 x 5/8" Ig. *
93
9373
Control Rod
94
8298
Idler Bracket Assembly
95
9371
Brake Lever
96
7805
Blade Spindle Ass'y. - complete H.W.
97
734-392
Tire - Rib Tread 16 x 1.75
98
736-147
External Lockwasher No. 10 Scr,
104
7919
Anti Scalp Plate - 8-1/2"
110
710-938
Allen Set Scr. - 1/4—28 x 1/4" Ig. * (not shown)
111
741-107
Bearing - Lower - Blade Spindle
113
734-439
Wheel Ass'y. - complete (rear)
114
736-154
Washer
115
721-105
Seal
116
737-479
Zerk Fitting
117
728-649
Rivet
118
754-647
Brake Shoe
119
7861
Clamp Bracket
120
710-407
Slot Hex Hd. Self Extr. Scr. No. 8—32 x .50" Ig.
121
746-171
Throttle Control - complete
122
736-112
Belleville Washer
123
736-169
Lockwasher 3/8 Scr. *
124
710-152
Hex Hd. Cap Scr. 3/8-24
X
1" Ig. *
718-132
Plastic Cap - rear wheel (not shown)
125
10769
Blade Adapter Kit
126
11193-458
Rear Protective Shield Assembly - complete
127
726-106
Push-on Flange Palnut
128
11145
Hinge Rod
129
11141-458
Chute Deflector
130
732-253
Torsion Spring
131
11131-458
Adapter Plate
132
711-555
Pivot Pin
11679-458
Chute Deflector Ass'y. - complete
(Includes Ref. No. 127, 129, 130, 131,132)
N
*For faster service, obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
(458 — Arctic Blue) — When ordering parts if color or finish is important, use the appropriate color code shown at
left. (e.g. Arctic Blue — 11650 (458) ).
FMintattintlM
The engine is not under warranty by the mower manufacturer. If repairs or service is needed
on the engine, please contact your nearest authorized engine service outlet. Check the
"Yellow Pages" of your telephone book under "Engines—Gasoline."
