PARTS LIST FOR ROTARY MOWER MODEL NO. 113-530 A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
732-158
Blade Tension Spring
2
754-109
V Belt - 1 / 2 x 4 3 *
3
736-300
Flat Washer-3/8 I.D.
4
710-373
Shoulder - Special
5
756-370
Idler Bearing Assembly
6
712-372
Centerlock - Hex Nut - 5/16—18" Thd. *
7
7353
Bracket - Belt
8
711-212
Sleeve
9
741-120
Bearing - Upper
10
719-120
Spindle Housing
11
712-123
Hex Nut-5/16-24 Thd. * t
12
710-117
Hex Hd. Cap Scr. - 5/16—24 x 1" Ig. (Heat Treated)
13
710-459
Hex Hd. Cap Scr. 3/8-24 x 1-1/2" Ig. (Heat Treated)
14
9383-513
Wheel Assembly - 8" - B.B. (Front)
15
738-213
Axle Bolt - 5/8 length Thd. (Front)
16
741-114
Ball Bearing (Front)
17
736-217
Spring Lockwasher 3/8 Heavy Duty Scr. *
18
10769
Blade Adapter Kit
19
736-119
Spring Lockwasher - 5/16 Scr. *
20
711-240
Spindle
21
742-125
Blade - 20"
22
710-122
Hex Hd. Cap Scr. 5/16-24 x 1" Ig. *
23
8324
Belt Guard
24
712-123
Hex Nut 5/16-24" Thd. *
25
710-122
Hex Hd. Cap Scr. 5/16—24 x 1" Ig. *
26
9925
Pulley — 4"
27
11650-458
Deck Assembly - 22"
28
710-192
Truss Mach. Scr. No. 10—24 x .38" Ig.
29
8280-458
Frame Assembly
30
736-921
Spring Lockwasher - 1/2" Scr. *
31
712-922
Hex Jam Nut - 1/2-20 Thd. *
32
710-102
Hex Hd. Cap Scr. 1 /4-20 x 2-1 /2 Ig. *
33
736-222
Ext. Lockwasher - 1/4 Scr. *
34
8295-458
Blade Spindle Cover
35
Engine
36
710-158
Hex Hd. Cap Scr. 5/16-24 x 1-1/4" Ig. *
37
714-365
Key - Hi Pro No. 505 * t
38
8328
Handle Support - Lower R.H.
39
736-108
Flat Washer - 33/64 I.D. *
41
9362
Handle - Lower H. W.
43
8327
Handle Support - Lower L.H.
44
8325
Belt Trap Assembly
46
738-234
Pivot Screw
47
9372
Pivot Bracket
49
756-110
Engine Pulley
50
712-430
Elastic Stop Nut - 3/8—16 Thd. *
51
8809
Reinforcement Plate
71
711-179
Ferrule
72
711-180
Control Rod
73
710-606
Hex Hd. Cap Scr. 1/4-20 x 1-1/2" Ig. *
74
710-106
Hex Hd. Cap Scr. 1/4-20 x 1-1/4" Ig. *
75
712-287
Hex Nut - 1/2-20 Thd.
76
712-107
Centerlock - Hex Nut - 1/4-20" Thd. *
77
11815-458
Control Panel
78
712-324
Elastic Stop Nut -1/4—20 Thd.
79
736-325
Flat Washer - .265 I.D. *
