OPTIONAL
PARTS LIST FOR MODEL 190-935A 44" DECK
REF.
NO.
PART COLOR
NO. CODE
DESCRIPTION
NEW
PART
REF,
NO.
PART COLOR
NO. CODE DESCRIPTION
NEW
PART
1 746-0237 Brake Cable Ass’y- (Deck) 37 738-0436 Blade Spindle—L.H.
2 726-0106 Push Cap V4" Stud 38 712-0123 Hex Nut 5/16-24 Thd.*
3 754-0230 “V”-Belt V 2 " X 56" Lg. 39 736-0119 L-Wash. 5/16" Scr.*
4 13910 Belt Guard (Deck) 40 710-0117 Hex Scr. 5/16-24 x 1.00" Lg.
5 710-0599 Hex Thd. Rolling V4-20 x .50" Grade 5
Lg-
41 710-0180 Hex Scr. 3/8-24 x .75" Lg.
6 712-0242 Hex Jam Nut 5/8-11 Thd. Grade 5
7 736-0317 Belle. Wash. 5/8" I.D. x 42 736-0217 L-Wash. 3/8" Scr. H.D.
1.25 O.D. 43 742-0125 22" Blade
8 756-0329 Deck Drive “V”-Pulley 44 714-0149 Hairpin Cotter
9 738-0140 Shid. Scr. .437" Dia. x .180" 45 738-0392 Deck Connecting Rod
Lg. 5/16-18 46 13867 Diagonal Brace
10 736-0141 Wave Wash. 7/16" Scr. 47 736-0192 FI-Wash. 1/2" I.D. X 1.00"
11 13908 Spindle Brake Arm Ass’y- O.D. X .090
12 13874 Belt Cover Ass’y. N 48 714-0111 Cotter Pin 3/32" Dia. x 1.00"
13 710-0599 Hex Thd. Rolling Scr. V4-20 x Lg.*
.50" Lg. 49 736-0105 Belle. Wash. 3/8" Scr.
14 712-0158 Hex Cent. L-Nut 5/16-18 Thd. 50 13868 Spindle Plate Ass’y.
15 754-0246 Timing Belt #1440'-8M-20 51 738-0437 Blade Spindle—R.H.
16 756-0334 Sprocket Pulley Ass’y. 52 710-0599 Hex Wash. Hd. Self-Tap Scr.
17 710-0322 Hex Sems Scr. 5/16-18 x 1/4-20 X .50" Lg.
1.00" Lg.* 53 711-0571 Hinge Pin
18 710-0754 Adjustment Scr. 54 11396 Grass Catcher Adapter Plate
19 738-0347 ShId. Spacer (Special) 55 11633 Chute Cover Ass’y.
20 750-0455 Spacer—Adj. Scr. 56 732-0261 Torsion Spring
21 736-0231 FI-Wash. 5/16" I.D. x 1.125" 57 726-0106 Push Nut 1 / 4 " Rod
O.D. 58 736-0219 Belleville Wash.
22 712-0267 Hex Nut 5/16-18 Thd.* 59 712-0181 Hex Nut 3/8-16 Thd.*
23 732-0377 Compression Spring 60 738-0455 Shid. Scr. .498 Dia. x 1.53"
24 13861 44" Deck Ass’y. Lg. 3/8-16
25 736-0105 Belleville Wash. 3/8" I.D. 61 734-0974 Wheel Ass’y. Comp. 6" N
26 712-0241 Hex Nut 3/8-24 Thd.* (Deck)
27 13866 Deck Stabilizer 62 736-0105 Belleville Wash. 3/8" I.D.
28 750-0456 Spacer 63 10937 Wheel Pivot Bar
29 09164 Reinforcement Plate 64 14082 Spring Lever Ass’y. w/Knob N
30 741-0919 Ball Bearing 65 732-0118 Extension Spring
31 08253 Bearing Housing 66 748-0279 Shid. Spacer
32 13703 Bearing Shield 67 710-0342 Hex Scr. 3/8-16 X 1.00" Lg.
33 714-0126 #9 Hi-Pro Key 3/16 x 3/4" Grade 5
Dia. 68 711-0701 Clevis Pin 1/4" Dia. x 1.00"
34 748-0235 Blade Adapter 3/4" Spindle Lg.
35 736-0119 L-Wash. 5/16" Scr.* 69 714-0104 Hairpin Cotter 1/4" Dia.
36 712-0267 Hex Nut 5/16-18 Thd.*
33
