Installation Instructions

GAS-FIRED AIR CONDITIONER

Installation of the Model 454 Gas Air Con­

ditioning unit consists of the following steps:

I. Locating and Mounting the Unit

II. Connecting Chilled Water Lines

III. Making Electrical Connections

IV . Making Gas Connections

V . Charging Systena with Water

VI. Checking the Unit Operation

VII. Adjusting Gas Input

VIII. Balancing the System

DC . Freezing Weather Protection

Each of the above steps is discussed in detail

in this instruction. Read the entire instruc -

tion before starting the installation.

Multiple Chillers and Cooling Coils

When it is planned to connect two or more

chillers or coils, additional piping and

electrical information is required and should

be obtained from your Bryant Distributor.

When making multiple chiller installations, it

is recommended that only 454 chillers be

interconnected. The use of other model chil­

lers with the

4 5 4

in a multiple system should

be avoided.

Operation at Atmospheric Pressure

The chilled water tank on this unit is vented

to the atmosphere; consequently, the chilled

water circuit operates at or near atmospheric

pressure.

Therefore, conventional piping practices for

a closed, pressurized system do not apply

for this unit.

NOTE: When the water chiller is piped to a

boiler as described below, the indoor coil

operates at or near atmospheric pressure

when used for cooling; it may be pressurized

when it is used with the boiler for heating.

SIZE 36

SERIES W

454

bri|ant

I

39454D1

4/25/69

■■1

Figure 1 - Model 454 Gas Air Conditioner

When this chiller is piped with a boiler to

form a combination heating and cooling sys -

tern, provisions must be made for a positive

shut-off between the chiller tank and the

boiler.

When the boiler is in operation, the chiller

tank must be by-passed. A sedime:

must be installed

when a common pipe (|oni

and boiler.

When the chiller is i:

of course, should be b;

LOCATING AND M
