4654870 • 11
10
11
Clip grease cup bracket onto bar at notches
Final Assembly
NOTE - Legs not shown for clarity IMPORTANT:
Bend tabs of insulation bowl straight down toward
grease cup to avoid grease spillage.
NOTE:
You may have hardware left over after completing assembly of your grill. This is normal as in some
cases we have included extra hardware to ensure that you have enough.
Raised Lip
Element
Bracket
Raised lip of controller should be
inserted until it is snug against
element bracket
Remove protective film from
controller prior to use.
Top View
H
Ensure that controller
knob is fully rotated
counterclockwise to
the OFF position prior
to plugging controller
into grill and outlet.
Congratulations, you have now completed the assembly of your grill. You can now
look forward to hours of enjoyable cooking. For your safety and optimum grill
performance finish reading the instructions on the following pages before using
your new grill.
