Char-Broil 4654870 User Manual
Page 10
10 4654870
IMPORTANT:
Orient heating element so that the notch is on TOP.
("BOTTOM" is stamped on underside of bracket.)
MISC Bag
8
772
418
Insulated
Washer
772
418
9
Push insulation side flaps
down flush with bowl.
Push center flap
down onto element.
B
A
Cooking grate rests on T-nuts
Slide element bracket thru slot in side of insulation bowl
and into rectangular slot in grill body. Element bracket
mounts snugly against inside of grill body.
