Appendix B - Specifications
65
PCMCIA Wireless Card
Interface
PCMCIA 68pin, 16bit data
Standards
IEEE802.11b WLAN, PCMCIA 2.1, JEIDA 4.2
Frequency
2.4 to 2.4835GHz ( Industrial Scientific Medical Band )
Channels
Maximum 14 Channels, depending on regulatory authorities.
Data Rate
11 / 5.5 / 2 / 1 Mbps
Coverage Area
Closed Space : 25m @11Mbps, 100m @5.5Mbps or lower
Power
DC +3.3V / 220mA
Output Power
13dBm (typical)
Receiver Sensitivity
-80dBm Min.
Operating Temperature
0
o
to 55
o
C
Storage Temperature
-25
o
to 70
o
C
Relative humidity
10% to 90%
PWR LED
ON - power available
OFF - no power
ACT LED
OFF - inactive
Blinking - Data transmitted or received.
