Installation Instructions
Vault w/ visor
C-Scroll w/ visor
Roundel w/ visor
These installation instructions are valid with the above Ametrix styles
Mounting Plate Dimensions In [mm]
Lamping Size Chart
(lamps provided by others)
Warning
: Before starting any work ensure
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Large, INDOOR
YR (30 1/2")
(Yoke mount, Remote ballast)
Visor and Non-Visor
Sheet 2 of 2
ADY071446 Rev A (ECN070295)
CL
325.9
32
12
"
27
23.2
29
"
32
346.9
"
13 32
21
651.7
"
25 32
21
114.3
"
4 2
1
57.2
"
2 4
1
173.5
"
6 32
27
14
15
16 "
379.3
Mounting dimensions are for 30 1/2"(774.7mm) large YR indoor only
FIXTURE SIZE
(inches/ m m )
WATTAGE
# OF
LAMPS
LAMP TYPE
LAMP DESCRIPTION
LAMP
(not to scale)
30
1/2
/ 774.7
36 W
1
T5
Twin Tube
30
1/2
/ 774.7
40 W
1
T5
Twin Tube
30
1/2
/ 774.7
50 W
1
T5
Twin Tube
30
1/2
/ 774.7
55 W
1
T5
30
1/2
/ 774.7
36 W
2
T5
Twin Tube
30
1/2
/ 774.7
40 W
2
T5
Twin Tube
30
1/2
/ 774.7
50 W
2
T5
Twin Tube
30
1/2
/ 774.7
55 W
2
T5
Twin Tube
30
1/2
/ 774.7
250 W
2
ET18
Metal Halide
30
1/2
/ 774.7
400 W
2
ET18
Metal Halide
30
1/2
/ 774.7
900 W
1
T3
Halogen(Double Ended)
30
1/2
/ 774.7
1000 W
1
T3
Halogen(Double Ended)
