COLORstrip™ User Manual (Rev. 5) Page 9 of 17
4. O
PERATION
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display.
Button Function
Press to find an operation mode or to back out of the current menu
option
Press to activate a menu option or a selected value
Press to scroll up the list of options or to find a higher value
Press to scroll down the list of options or to find a lower value
Menu Map Mode Programming Steps Description
ACt
Automatic
Operation
(extra levels not
available in all
programs)
A000-A023
F000-F100 Flash speed (slow to fast)
P000-P100 Run speed (slow to fast)
C000-C100 Color
SYS
SdAd 000-509 Set DMX address
SAAd Reset software
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting Address When selecting a starting DMX address, always consider the number of DMX channels
the selected DMX mode uses. If you choose a starting address that is too high, you could
restrict the access to some of the product’s channels.
The COLORstrip™ uses up to 4 DMX channels in its 4-channel DMX mode, which
defines the highest configurable address to 509.
If you are not familiar with the DMX protocol, see the DMX Primer online at
www.chauvetlighting.com
To select the starting address, do the following:
1. Press
repeatedly until SYS or ACt shows on the display.
2. Use or to select SYS.
3. Press .
4. Use or to select SdAd from the menu.
5. Press .
6. Use or to select the starting address.
7. Press .
