COLORstrip™ User Manual (Rev. 5) Page 17 of 17
6. T
ECHNICAL
S
PECIFICATIONS
Dimensions and
Weight
Length Width Height Weight
38 in (965 mm) 2.5 in (64 mm) 6 in (152 mm) 4.5 lbs (2 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power Power Supply Type Range Voltage Selection
Switching (internal) 100~240 V, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 72 W 73 W
Operating 0.6 A 0.3 A
Power linking current (units) 8 A (15 units) 8 A (28 units)
Fuse F 1 A, 250 V F 1 A, 250 V
Power I/O US/Worldwide UK/Europe
Power input connector IEC IEC
Power output connector Edison IEC
Power Cord plug Edison (US) Local plug
Light Source Type Lifespan
LED 50,000 hours
Color Quantity
Red 128
Green 128
Blue 128
Photo Optic Parameter
Illuminance @ 2 m 618 lux
Beam angle 53º x 27°
Field angle 68° x 46°
Thermal Maximum External Temp. Cooling System
104° F (40° C) Convection
DMX I/O Connectors Connector Type Channel Range
3-pin XLR Sockets 4
Ordering Product Name Item Code Item Number
COLORstrip™ 02030122 COLORSTRIP
