MTD 249-610-000 - Manual (Page 13)

Model 610
PARTS LIST FOR MODEL 610 LOG SPLITTER
REF.
NO.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 781-0038 Wedge Ass’y- 37 712-0203 Hex Nut 3/4-10 Thd.*
2 710-0520 Hex Bolt 3/8-16 X 1.5" Lg. 38 736-0364 L-Wash. 3/4" I.D.*
(Gr. 5) 39 712-0338 N Hex Nut 1-1/16-12 Thd.
3 736-0262 FI-Wash. .375" I.D. x .87" O.D. 40 736-0275 FI-Wash. .34" I.D. x .68" O.D.
4 713-0338 Chain—Tow Hitch 41 712-0158 Hex L-Nut 5/16-18 Thd.
5 750-0507 Spacer .38" I.D. x .625" O.D. 42 737-0259 90° Adapter 3/4" Hose
6 710-0298 Hex Bolt 5/8-18 x 3.5" Lg. 43 781-0021 Strainer Tube Ass’y.
7 710-3130 Hex Bolt 3/8-16 X 3.25" Lg. 44 737-0191 Adapter 1" x 1-1/16-12 Thd.
(Gr. 8) 45 726-0132 Hose Clamp 5/8"
8 727-0289 Tow Hitch Ass’y- 46 727-0429 N Suction Hose 1" I.D.
9 750-0261 Spacer .375" I.D. x .625" O.D. 47 737-0265 90° Adapter
10 736-0169 L-Wash. 3/8" I.D.* 48 717-0936 N Two Volume Pump (Incl. Ref. 75)
11 712-3017 Hex Nut 3/8-16 Thd. (Gr. 5) 49 712-0123 Hex Nut 5/16-24 Thd.*
12 781-0311 N Beam Stand 50 736-0119 L-Wash. 5/16" I.D.*
13 712-0337 Hex Nut 5/8-18 Thd.* 51 714-0122 Sq. Key 3/16 x .75" Lg.
14 736-0158 L-Wash. 5/8" I.D.* 52 781-0097 Rear Coupling Support Bracket
15 781-0343 452/N Oil Tank Ass’y. 53 710-0117 Hex Bolt 5/16-24 x 1.0" Lg.*
16 738-0601 Shid. Bolt .62" Dia. x .475" 54 719-0278 Coupling Shield
17 719-0269B N Pusher Plate 55 717-0891 Flexible Coupling
18 638/N Hydraulic Cylinder 56 710-0237 Hex Bolt 5/16-24 x .62" Lg.
19 737-0238 Pipe Nipple Vz" NPT x 2" Lg. 57 781-0098 Front Coupling Support Bracket
20 737-0192 90° Solid Male Adapter 58 710-0363 Hex Bolt 5/16-24 X 4.0" Lg.
21 717-0942 Control Valve 59
—
Engine
22 737-0153 Return Elbow 60 710-0409 Hex Bolt 5/16-24 x 1.75" Lg.*
23 726-0146 Adjustable Hose Clamp 61 712-0241 Hex Nut 3/8-24 Thd.*
^24 737-0171 90° Solid Male Adapter 62 710-0152 Hex Bolt 3/8-24 x 1.0" Lg.*
25 727-0430 N High Pressure Hydraulic Hose 63 750-0442 Spacer .75" I.D. x 1.12" O.D.
29.5" Lg. 64 738-0405 Wheel Axle
26 727-0435 N Return Hose 3/4" I.D. x 23V2" 65 781-0019 Axle Mounting Plate
Lg. 66 781-0033B N Engine Frame Ass’y.
27 727-0307 Metal Pressure Tube 67 734-1016 Wheel Ass’y. Comp.
28 745-0174 Cap 734-0872 Tire Only
29 781-0036 Filler Tube Ass’y. 68 734-0255 Air Valve
30 721-0204 “0”-Ring .92" I.D. 69 721-0168 Bearing Seal
31 720-0231 N Ball Knob 70 734-1017 Rim Only
32 747-0709 N Control Handle 71 741-0107 Roller Bearing w/Race
33 710-1036 Hex Bolt 3/4-10 X 4.5" Lg. 72 712-0299 Hex Slotted Nut 3/4-16 Thd.
34 710-0442 Hex Bolt 5/16-18 X 1.5" Lg.‘ 73 734-0873 Hub Cap
35 781-0361 N Beam End Plate 74 714-0162 Cotter Pin 5/32" Dia.
36 721-0203 Gasket 75 714-3024 N Hi-Pro Key 1/8" X 1/2" Lg.
‘For faster service obtain standard nuts, bolts and washers locaily.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
NOTE: The engine is not under warranty by
the iog spiitter manufacturer... If repairs or
service is needed on the engine, please
contact your nearest author­
ized engine service outlet.
Check the “Yellow Pages” of
your telephone book under
“Engines—Gasoline.”
Find It Fast
In The
Yellow Pages
13
