MTD 249-620-003 - Manual (Page 17)

PRO/20 (Model 620)
PARTS LIST FOR MODEL 620 LOG SPLITTER
lEF.
»lO. PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 736-0119 L-Wash. 5/16" I.D.* 49 736-0171 L-Wash. 7/16" I.D.*
2 710-0117 Hex Bolt 5/16-24 x 1" Lg. 50 781-0315 N Beam Mtg. Plate
3 710-0237 Hex Bolt 5/16-24 x .62" Lg. 51 781-0334 N Beam Latch Bracket
4 710-0363 Hex Bolt 5/16-24 x 4" Lg. 52 781-0340 Vertical Beam Ass’y.
5 712-0123 Hex Nut 5/16-24 Thd. 57 5 H.P. Engine
6 714-0122 Sq.-Key 3/16 x .75 60 717-0885B N Hydraulic Cylinder 4" Dia.
7 717-0891 Flexible Coupling 61 714-0203 N External Cotter Pin
8 717-0936 N Two Volume Pump 62 715-0206 N Cylinder Mtg. Pin
9 719-0278 Coupling Shield 63 717-0886 Control Valve—3000 PSI
10 726-0132 Hose Clamp 5/8" 64 727-0307 Metal Pressure Tube Vz" O.D.
11 727-0427 N Suction Hose 1" I.D. 65 727-0440 •N Pressure Tube V 2" Dia.
Ir12 727-mS» N High Pressure Hydraulic 66 737W7-I 90° Solid Male Adapter
0433 Hose W 67 ’'SUi^fiL CPOO\ < 67 737-0192 90° Solid Male Adapter
14 781-0097 Rear Coupling Support Brkt. 68 737-0235 3 / 4 " Dia. Hose Barb
15 781-0098 Front Coupling Support Brkt. 69 737-0238 Pipe Nipple Vz NPT
16 781-0337 Tank Ass’y. Complete 73 710-1010 Bolt Vz X 3
17 710-0409 Hex Bolt 5/16-24 x 1.75" Lg.* 74 710-1018 Hex Bolt Vz-20 x 2.75" Lg.—
18 710-3160 Hex Bolt 1/2-20 X 4" Lg.—Gr. 5 Gr. 8
19 712-0123 Hex Nut 5/16-24 Thd.* 75 710-1032 N Hex Bolt 3/8-24 x 1.5" Lg.
20 712-0333 Nut 1/2 BL NF-20 76 712-0239 Hex L-Nut Vz-20 Thd.
21 736-0119 L-Wash. 5/16" I.D.* 77 712-0333 Nut Vz BL NF-20 Thd.
22 736-0921 L-Wash. 1/2" I.D.* 78 712-3001 Hex Jam Nut 3/8-24 Thd.—Gr. 5
23 737-0236 Pipe Plug 79 736-0921 L-Wash. Vz" I.D.
24 750-0739 N Pivot Bushing .75" O.D. 80 750-0743 N Spacer Vz" I.D. x 3/4" O.D.
25 781-0312 N Strainer Ass’y. 81 781-0323 N Wedge Mtg. Ass’y.
|26 735-0639 Spark Plug Cover 87 781-0345 N Pusher Back Plate
27 723-0405 Filter Element 88 781-0350 N Fixed Side Gib
29 723-0406 Filter Head 89 781-0351 N Adj. Gib 2" Lg.
30 726-0146 Adjustable Hose Clamp 90 781-0352 N Adj. Gib Shim 10" Lg.
31 727-0309 Return Hose %" I.D. x 30" Lg. 91 781-0356 N Floating Gib Plate
32 737-0235 3A" Dia. Hose Barb 95 710-0521 Hex Bolt 3/8-16 X 3" Lg.-Gr. 8
33 712-0299 Hex Castle Nut 3/4-I6 Thd. 96 710-3130 Hex Bolt 3/8-16 X 3.25" Lg.—
34 714-0162 Cotter Pin 5/32" Gr. 8
35 734-0873 Hub Cap 97 711-0820 Quick Release Pin
36 734-1016 Wheel Ass’y. Comp. 99 712-0375 Hex L-Nut 3/8-16 Thd.
734-0872 Tire Only 100 712-0798 Hex Nut 3/8-16 Thd.*
734-1017 Rim Only 101 713-0338 Chain—Tow Hitch
734-0255 Air Valve 102 727-0311 Hitch Coupler
37 741-0107 Roller Brg. W 103 736-0169 L-Wash. 3/8
38 736-0351 FI-Wash. .760" I.D. X 1.5" O.D. 104 736-0185 FI-Wash. .406" I.D. x .75
39 750-0442 Spacer .75" I.D. x 1.12" O.D. 105 750-0507 Spacer .38" I.D. x .625" O.D.
40 710-0117 Hex Bolt 5/16-24 x 1" Lg.* 106 781-0316 Tongue Tube
41 710-0514 Hex Bolt 3/8-16 X 1" Lg.-Gr. 5 107 781-0358 Jack Stand Ass’y.
42 710-3029 Hex Bolt 7/16-20 x 1.25" Lg.— 112 710-0831 Hex Bolt 3/8-16 X 5.5" Lg.
Gr. 5 113 710-3144 Hex Bolt 3/8-16 X 2" Lg.-Gr. 5
43 711-0820 Quick Release Pin 114 712-0430 Hex Insert L-Nut 3/8-16 Thd.
44 712-0123 Hex Nut 5/16-24 Thd.* 115 750-0745 Spacer 4" Lg.
45 712-3017 Hex Nut 3/8-16 Thd.—Gr. 5 116 781-0168A N Stripper Half
46 712-3067 Hex Patch L-Nut 7/16-20 Thd. 117 720-0231 Ball Knob i
47 736-0119 L-Wash. 5/16" I.D.* 118 747-0709 Control H a n d \ e M A h '
48 736-0169 L-Wash. 3/8" I.D.* L míü ^S&E a J c T
uKiLs^s ató caen:
X7b
‘For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
17
