SERVICE AND ADJU

ind washers to
ins a square key

ттчЛ

»Л/HLLL

гои

Пбг PAIRS

{See ria. zbi

Block up axle securely.
Remove axle cover,

h V r ^ f • >'i t •' >■ (fi

- Do not lose).

I’ [ire if I rra t h r i

only -ir.ii ijrooves in rear wheel hub

Of d Do I', t rt suu_i- I ' j

FppDif wd rets and sri-:;^ teraifiing ring securely in

3?ie u.ofn'e

F, ю!ле t_xlp f o'/ct

NOTE 1 о se J tire pUt rfuie.... anJ pteverr flat tires due to

slow It ai c, tin ; er.Nnr Ti s' hr t la* ha„c-i from your local

parts dealer. Tire .ealatit also pisvent:^ tire dry rot and

corrosion.

WASHERS

RETAINING

RING

AXLE COVER

SQUARE KEY

(REAR WHEEL ONLY)

FIG. 28

TO START ENGINE WITH A WEAK BATTERY

(See Fig. 29)

CAUTION: Lead-acid batteries gener-

ate explosive gases. Keep sparks, flame

and smoking materials away from bat
teries. Always wear eye protection
when around batteries.

If your battery is too weak to start the engine, it should be

recharged. If “jumper cables” are used for emergency
starting, follow this procedure:
IMPORTANT: YOUR TRACTOR IS EQUIPPED WITH A 12

VOLT NEGATIVE GROUNDED SYSTEM. THE OTHER
VEHICLE MUST ALSO BE A 12 VOLT NEGATIVE

GROUNDED SYSTEM. DO NOT USE YOUR TRACTOR
BATTERY TO START OTHER VEHICLES.

TO ATTACH JUMPER CABLES -

•

Connect each end of the RED cable to the POSITIVE

(+) terminal of each battery, taking care not to short

against chassis.

•

Connect one end of the BLACK cable to the NEGA

TIVE {-) terminal of fully charged battery.

•

Connect the other end of the BLACK cable to good

CHASSIS GROUND, away from fuel tank and battery.

TO REMOVE CABLES, REVERSE ORDER -

•

BLACK cable first from chassis and then from the fully

charged battery.

•

RED cable last from both batteries.

POSITIVE
TERMINAL

CHAbw-

POSITIVE

TERMINAL

IVE

TERMINAL

rüBLES

CHARGED
BATTERY

NEGATIVE

(EHMINAL

FIG. 2 9

TO REPLACE HEADLIGHT BULB

•

Raise hood.

•

Pull bulb holder out of the hole in the backside of the

grill.

® Replace bulb in holder and push bulb holder securely

back into the hole in the backside of the grill.

•

hood.

INTERLOCKS ÄND RELAYS

Loose or damaged wiring may cause your tractor to run
poorly, stop running, or prevent it from starting.

•

Check wiring. See electrical wiring diagram in the

Repair Parts section of this manual.

TO REPLACE FUSE

Replace with 30 amp automotive-type plug-in fuse. The

fuse holder is located behind the dash.

TO REMOVE HOOD AND GRILL ASSEMBLY
(See Fig. 30)

•

Raise hood.

•

Unsnap headlight wire connector.

•

Stand in front of tractor. Grasp hood at sides, tilt toward
engine and lift off of tractor.

•

To replace, reverse above procedures.
