GENERAL
INFORMATION
Section 1 - General Information
PRIMEPACT 70G and 70LP Recreational Vehicle Generators
Figure 1.1 - Connection for 120 Volts Only Fuel Consumption (gph/ibs.ph)
Figure 1.2 - Connection for 120/240 Volts
1.6 SPECIFICATIONS
♦ 1.6.1 FUEL REQUIREMENTS
'I'llis <>('ncralor is equijiped with a gasoline fuel system
as standard e(|uipinent. Specific installations may pro­
vide either a separate fuel tank for the generator, or the
generator may ''share’' the veliicle engine's fuel tank.
Model No Load 1/2 Load Full Load
PrimePact 70G 0.34 0.65 1.12
PrimePact 70LP 0.47/2.01 0.85/3.62 1.66/7.05
NOTE
Some installations using a “shared” fuel tank may
have a generator fuel pickup tube that is shorter
than the vehicle engine’s pickup tube. Such an
arrangement causes the generator engine to “run
out of gas” while adequate fuel for the vehicle
remains in the tank.
To reduce lead and carbon deposits use high quality
UNLEADED
gasoline with the generator. Leaded
REGULAR grade gasoline is an acceptable substitute.
NOTE:
Using unleaded gasoline contributes to longer engine
valve life by reducing lead and carbon deposits.
-A CAUTION A-
A Generac does not recommend using any
gasoline containing alcohol (such as "gasohol").
If you use any gasoline containing alcohol, it
must not contain more than 10 percent ethanol,
and it must be removed from the generator
during storage. Do NOT use any gasoline
containing methanol. If you use gasoline with
alcohol, inspect more frequently for fuel leaks
and other abnormalities.
♦ 1.6.2 ENGINE OIL REQUIREMENTS________________
Use only high quality detergent oil classified “For
Service SF” and with an oil viscosity rating of SAE
lOW-30 oil. Do not pour in any additives to the rec­
ommended oil. Engine crankcase capacity is 1.4
liters. See Section 3.2 on page 11 for oil level check
and filing procedures.
♦ 1.6.3 GENERATOR SPECIFICATIONS
SERIES PRIMEPACT 70G PRIMEPACT 70LP
Rotor RPM 3600 3600
Rotor Poles 2 2
Engine RPM 2900 2900
Rated Max. Continuous AC Output* 7000 waits (7.0 kW) 6600 watts (6,6 kW)
Voltage* 120 120
Rated Max. Continuous Current* 58.3 AC ampsf 55.0 AC amps N
Phase 1 1
Frequency 60 Hertz 60 Hertz
Battery Charging Current (Max.) 10 amps (regulated) 10 amps (regulated)
Weight 221 pounds 224 pounds
Length 25 inches 25,75 inches
Width 18.5 inches 18.5 inches
Height 15.75 inches 15.75 inches
■ All units are reconnectable to 120 and’or 240 volts, dual voltage output. Units are not listed per RVIA'ANSI when reconnected for dual voltage output
f Rated maximum continuous current at 240 volts is 29,2 amps,
N Rated maximum continuous current at 240 volts is 27.5 amps.
